2023 Yamaha TT-R125LE

Stock #64147
MSRP: $3,399 USD

285 people have recently viewed it.
Check Availability Hi, my name is and I'm interested in this 2023 Yamaha TT-R 125LE . I'm in the area and you can reach me at or on my phone at .

VIEW SPECS

FUN FOR ONE. FUN FOR ALL.

A versatile off‑road bike that's perfect for discovering the fun and freedom of trail riding.



YOU'RE IN CONTROL.

Torque-Rich Engine

Potent 124cc air-cooled SOHC four-stroke powerplant puts out torquey, broad power tuned for off-road performance in a wide range of trail conditions.

RESPONSIVE POWER

Crisp, dependable throttle response from the 20mm Mikuni® carburetor.

DIGITAL IGNITION

CDI ignition system is ultra-reliable and never needs maintenance.



TT-R125LE

125 CC FOUR-STROKE ENGINE

124cc Air-cooled SOHC 4-stroke; 4 valves




198 LBS (WET) WEIGHT

FULLY FUELED WEIGHT OF ONLY 198 POUNDS (FUEL & EQUIPMENT)




1.6 GALLON FUEL CAPACITY

The compact style gas tank holds a full 1.6-gallon for trail riding.

  • Status:
    New
  • Vehicle:
    2023 Yamaha TT-R125LE
  • VIN:
    9C6CE22E7P0004147
  • Model Number:
    TTR125LEPC
  • Color:
    Team Yamaha Blue
  • Stock Number:
    64147
  • Title:
    Clear
  • Location:
    Motor Sports of Willmar
  • Warranty:
    Manufacturer's w/ Extended Available

BRAKES

  • Front Brake Diameter (in):
    8.7
  • Front Brake Diameter (mm):
    220
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    4.3
  • Rear Brake Diameter (mm):
    110
  • Rear Brake Type:
    Drum

ENGINE

  • Bore (in):
    2.13
  • Bore (mm):
    54
  • Carburetion Brand:
    Mikuni
  • Carburetion Type:
    Carburetor
  • Carburetor Size (mm):
    20
  • Carburetor:
    Yes
  • Compression Ratio:
    10.0
  • Cooling:
    Air
  • Cylinders:
    1
  • Displacement (cc):
    124
  • Displacement (ci):
    7.6
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    Single-Cylinder
  • Fuel Requirements:
    Regular
  • Fuel Type:
    Gas
  • Number Of Carburetors:
    1
  • Starter:
    Electric
  • Stroke (in):
    2.13
  • Stroke (mm):
    54
  • Valve Configuration:
    SOHC
  • Valves Per Cylinder:
    2
  • Valves:
    2

EXTERIOR

  • Body Material:
    Plastic
  • Chain Guard:
    Yes
  • Exhaust Guard:
    Yes
  • Foot Peg Location:
    Driver
  • Fork Guards:
    Yes
  • Frame:
    Steel
  • Heel Guards:
    Yes
  • Stand Type:
    Kick

SEATS

  • Number Of Seats:
    1
  • Seat Height (in):
    31.7
  • Seat Height (mm):
    805.2
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Type:
    One-Piece

STEERING

  • Steering Control:
    Handlebar

SUSPENSION

  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Suspension Size (in):
    1.2
  • Front Suspension Size (mm):
    31
  • Front Suspension Type:
    Telescopic Fork
  • Front Travel (in):
    7.1
  • Front Travel (mm):
    180.3
  • Number Rear Shock Absorbers:
    1
  • Rear Adjustable Rebound Damping:
    Yes
  • Rear Suspension Material:
    Aluminum
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    6.6
  • Rear Travel (mm):
    167.6

TECHNICAL SPECIFICATIONS

  • Engine Displacement to Weight (cc):
    0.63
  • Fuel Capacity (gal):
    1.6
  • Fuel Capacity (l):
    6.1
  • Ground Clearance (in):
    11.6
  • Ground Clearance (mm):
    294.6
  • Height (in):
    42.7
  • Height (mm):
    1084.6
  • Length (ft):
    6.18
  • Length (ft/ft):
    6
  • Length (ft/in):
    2.2
  • Length (in):
    74.2
  • Length (mm):
    1884.7
  • Wet Weight (kg):
    89.8
  • Wet Weight (lbs):
    198
  • Wheelbase (in):
    50
  • Wheelbase (mm):
    1270
  • Width (in):
    31.3
  • Width (mm):
    795

TRANSMISSION

  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Chain
  • Transmission Type:
    Manual

WHEELS & TIRES

  • Front Tire (Full Spec):
    IRC iX05H
  • Front Tire Aspect Ratio:
    100
  • Front Tire Speed Rating:
    M
  • Front Tire Width:
    70
  • Front Wheel Diameter:
    19
  • Rear Tire (Full Spec):
    IRC iX05H
  • Rear Tire Aspect Ratio:
    100
  • Rear Tire Speed Rating:
    M
  • Rear Tire Width:
    90
  • Rear Wheel Diameter:
    16
  • Tire Brand:
    IRC
  • Tube / Tubeless:
    Tubed
  • Wheels Composition:
    Aluminum
