PACKAGE HIGHLIGHTS • Smart-Lok* front differential • FOX† 2.5 PODIUM RC2† piggyback shocks • Belt monitoring system • 850 W magneto • 7.6 in. digital display with keypad • X-package graphics/seats • 4-point harness with shoulder pads • Can-Am LED signature • 14 in. aluminum beadlock wheels • Full roof • HMWPE full skid plate
ENGINE
TURBO RR Type--200 hp, Rotax® ACE (Advanced Combustion Efficiency)
900 cc turbocharged triple-cylinder engine, liquid-cooled
with integrated intercooler and high-perfomance air filter
Fuel Delivery System--Intelligent Throttle Control (iTC™)
with Electronic Fuel Injection (EFI)
Transmission-- pDrive primary and Quick Response System X (QRS-X) CVT
with high airflow, L/H/N/R/P
Drive Train-- Lockable front differential with exclusive Smart-Lok
technology. True 4 modes traction system: 2WD/4WD
with front diff. lock/4WD TRAIL ACTIV/4WD TRAIL
Power Steering-- High-torque Tri-Mode Dynamic Power Steering (DPS™)
SUSPENSIONS
Front Suspension--Double A-arm with sway bar/20 in. (50.8 cm) travel
Front Shocks-- FOX 2.5 PODIUM RC2 Piggyback with dual speed
compression and rebound adjustments
Rear Suspension-- 4-link Torsional Trailing-arm X (TTX)
with sway bar/20 in. (50.8 cm) travel
Rear Shocks-- FOX 2.5 PODIUM RC2 Piggyback with dual speed
compression, rebound adjustments and bottom-out control
TIRES & WHEELS
Tires-- Maxxis Carnivore†
30 x 10/10 x 14 in.
Wheels-- 14 in. cast-aluminum beadlock
BRAKES
Front-- Dual 262 mm disc brakes with hydraulic twin-piston calipers
Rear-- Dual 248 mm disc brakes with hydraulic twin-piston calipers
DIMENSIONS & CAPACITIES
Estimated Dry Weight-- 1,838 lb (833.7 kg)
Chassis/Cage-- Dual-phase 980 steel
L x W x H 164 x 64 x 66 in. (416.6 x 162.5 x 167.6 cm)
Wheelbase-- 135 in. (342.9 cm)
Ground Clearance-- 13 in. (33 cm)
Rack Capacity-- 150 lb (68 kg) with LinQ® Quick-Attach
Storage Capacity-- Total: 3 gal (11.4 L)
Fuel Capacity-- 10.5 gal (40 L)
FEATURES
Gauge-- 7.6 in. wide digital display with keypad
Instrumentation-- DC outlet (10-A)
Anti-theft System-- RF Digitally Encoded Security System (D.E.S.S.™)
with Start/Stop button
Lighting-- LED headlight, LED signature, LED tail lights
Winch-- N/A
Magneto-- 850 W
Protection-- Integrated front bumper, quarter doors, full roof
4-point harness with shoulder pads
HMWPE full skid plate, rear tow hook
WARRANTY & EXTENDED SERVICE
Factory Warranty 6-month BRP limited warranty
Extended Service
Terms
B.E.S.T. term available up to 30 months
